Questyle M15C Portable DAC & Headphone Amplifier
QUESTYLE
Description / Questyle M15C Portable DAC & Headphone Amplifier
The M15C was created for a very simple reason: Questyle’s fans wanted a compact portable audio dongle with Cirrus Logic's flagship CS43198 DAC chip. Based on the excellent market feedback of the M15 and the M15i, Questyle has kept the current-mode amplifier fundamentals of the M15 series and changed the DAC chip to CS43198, upgraded the USB control chip, and the M15C was born!
The M15C is equipped with four current-mode amplifier chips, and both 3.5mm unbalanced and 4.4mm balanced earphone jacks. It also includes a manual gain adjustment to accommodate for different headphones and audio system requirements.
Features
- CS43198 DAC
- Upgraded USB Control Chip
- Aluminum CNC Chasis With Transparent Window
- 3.5mm SE and 4.4 Balanced Output
- Dynamic Sample Rate Display
Product Inclusions
- Questyle M15C Portable DAC & Headphone Amplifier
- USB Type-C to Type-C Cable
- USB Type-C to Type-A Adapter
- Warranty Card
- Instructions
Specifications
| Category | Details |
|---|---|
| Compatible operating systems |
Android phones and tablets: supports Android 5.1 and above PCs: supports Win 10/11 Apple phones: supports iOS Apple computers: supports macOS |
| Decoding capability |
PCM: 44.1kHz – 384kHz (16/24/32Bit) DSD: DSD64(1Bit 2.8MHz), DSD128(1Bit 5.6MHz), DSD256(1Bit 11.2MHz) |
| Output interface |
3.5mm unbalanced headphone jack 4.4mm balanced headphone jack |
| Output power |
3.5mm: RL=300Ω, Po=10.72mW, output peak voltage up to 5.068Vpp,THD+N=0.00032% 4.4mm: RL=300Ω, Po=42.79mW, output peak voltage up to 10.13Vpp,THD+N=0.00028% |
| Frequency response | ±0.1dB 20Hz-20kHz; ±1dB 20Hz - 80kHz |
| DAC | Cirrus Logic flagship CS43198 DAC chip |
| Material | CNC anodized aluminum alloy |
| Color | Silver |
| Dimensions | 61.9[L] X 27.9[W] X 12[D] mm |
