Description / EarMen Tradutto Desktop DAC
Ultra High Resolution Balanced DAC
The Tradutto is a sophisticated DAC designed to enhance your digital audio experience. The ES9038Q2M DAC allows for outstanding sound performance and easily handles digital audio files up to 32bit/768kHz or DSD512, with MQA Decoding support. Furthermore, the whole circuit is optimized to draw less current and improve power filtering, resulting in low interference from Wi-Fi, cellular, and Bluetooth signals.
Designed for a variety of digital sources, the Tradutto supports digital optical, digital coaxial and USB inputs. The Tradutto features Bluetooth 5.1 input support with a wide variety of codecs (AAC/SBC/aptX/aptx LL/aptx HD).
Tradutto is fully balanced, which means that the balanced 4.4mm output from the DAC chip is preserved all the way to the balanced 4.4mm line output.
Exceptional Workmanship
Tradutto's chassis is milled from a single block of aluminum, which makes it extremely durable and robust. The compact design makes it fit any environment or home. The PCB is embedded in the solid aluminum housing, giving the board greater protection inside the housing and additional insulation from external inteference.
Specifications
| Inputs | BlueTooth QCC5124 | Bluetooth 5.1â„¢ ( AAC, SBC, aptX, aptX HD, aptX LL ) |
| USB | ||
| TOSLINK | S/PDIF optical | |
| Coax | S/PDIF | |
| Outputs | RCA (SE output) | output impedance = 300 Ω |
| Balanced 4.4mm | output impedance = 600 Ω | |
| Audio Formats | PCM | up to 768kHz |
| DSD | DoP64, DoP128, DoP256, native DSD512 | |
| DXD | up to 768kHz | |
| MQA | OFS (MQB/MQA Core), MQA, MQA Studio | |
| Bluetooth | 44.1kHz – 192kHz/16bit – 24bit | |
| Single-end output | ||
| USB input | S/PDIF input/BT | |
| Output Level | 2Vrms 0dBFS | 2Vrms 0dBFS |
| THD+N | 0.0003% | 0.0003% |
| SNR | >116dB | >116dB |
| A-Weighted | A-Weighted | |
| Freq. Response | ±0.014dB | ±0.006dB |
| Fully Balanced Output | ||
| USB input | S/PDIF input/BT | |
| Output Level | 4Vrms 0dBFS | 4Vrms 0dBFS |
| THD+N | 0.0003% | 0.0003% |
| SNR | >120B | >122dB |
| A-Weighted | A-Weighted | |
| Freq. Response | ±0.03dB | ±0.003dB |
| Dimension LxHxW | 150x30x150 mm | 5,9"x1,18"x5,9" |
| Weight | 550 gr | 1,21lbs |
